Angle section GreenTrellis

제품 라인업 — Anchoring elements · Angle sections

Angle section GreenTrellis

No.	b1	b2	s	kg
30922-4040-0850	800	850	200	2.0760
Further informations Standard and Classification: DIN 1028/EN 10056 Surface: rolled and stained Weight: 2.0760 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30922-4040-1450	1400	1450	200	3.5470
Further informations Standard and Classification: DIN 1028/EN 10056 Surface: rolled and stained Weight: 3.5470 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30922-4040-2050	2000	2050	200	5.0180
Further informations Standard and Classification: DIN 1028/EN 10056 Surface: rolled and stained Weight: 5.0180 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
