제품 라인업 — Anchoring elements · Tube bracket and Lug for welding
| No. | b1 | b2 | b3 | b4 | b5 | b6 | b7 | c | c1 | c2 | k | ø d1 | ø d2 | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 30924-0042-044 | 120 | 80 | 15 | 15 | 80 | 20 | 35 | 78 | 34 | 34 | 10 | 44 | 13 | 0.9700 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
