제품 라인업 — Anchoring elements · Tube bracket and Lug for welding
| No. | ø | b1 | b2 | b3 | b4 | b5 | b6 | b7 | c | c1 | c2 | c3 | k | ø d1 | ø d2 | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 30924-0033-044 | 5 | 120 | 80 | 15 | 15 | 70 | 25 | 36 | 70 | 36 | 26 | 26 | 8 | 36 | 13 | 0.7310 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
