2-part clamp ring light self-assembly

제품 라인업 — Carriers · Clamp- and flange rings

2-part clamp ring light self-assembly
No. ø a b ø d sw F_Rd kN F_rk kN kg
30863-0200 2 M4 10 15 3 0.6 0.7 0.0120
30863-0300 3 M4 10 15 3 0.6 0.7 0.0120
30863-0400 4 M4 10 15 3 0.6 0.7 0.0120
30863-0500 5 M4 10 20 3 0.6 0.7 0.0200
30863-0600 6 M4 10 20 3 0.6 0.7 0.0200
30863-0800 8 M4 10 20 3 0.6 0.7 0.0180
30863-1000 10 M6 15 32 5 1.3 1.6 0.0720
30863-1200 12 M6 20 32 5 1.3 1.6 0.0950

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
