2-part flange ring with two holes self-assembly

제품 라인업 — Carriers · Clamp- and flange rings

2-part flange ring with two holes self-assembly

No.	ø	a	b	k	ø d1	ø d2	ø d3	ø d4	F_Rd kN	F_rk kN	kg
30863-0200-01	2	M4	11	1.5	30	15	22.5	3.2	0.6	0.7	0.0190
Further informations Diameter: 2 mm Weight: 0.0190 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30863-0300-01	3	M4	11	1.5	30	15	22.5	3.2	0.6	0.7	0.0190
Further informations Diameter: 3 mm Weight: 0.0190 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30863-0400-01	4	M4	11	1.5	30	15	22.5	3.2	0.6	0.7	0.0190
Further informations Diameter: 4 mm Weight: 0.0190 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30863-0500-01	5	M4	11	1.5	35	20	27.5	3.2	0.6	0.7	0.0280
Further informations Diameter: 5 mm Weight: 0.0280 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30863-0600-01	6	M4	11	1.5	35	20	27.5	3.2	0.6	0.7	0.0280
Further informations Diameter: 6 mm Weight: 0.0280 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30863-0800-01	8	M4	11	1.5	35	20	27.5	3.2	0.6	0.7	0.0270
Further informations Diameter: 8 mm Weight: 0.0270 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
