2-part flange ring without drilling self-assembly

제품 라인업 — Carriers · Clamp- and flange rings

2-part flange ring without drilling self-assembly

No.	ø	a	b	k	ø d1	ø d2	F_Rd kN	F_rk kN	kg
30863-0200-02	2	M4	11	1.5	30	15	0.6	0.7	0.0190
Further informations Diameter: 2 mm Weight: 0.0190 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30863-0300-02	3	M4	11	1.5	30	15	0.6	0.7	0.0180
Further informations Diameter: 3 mm Weight: 0.0180 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30863-0400-02	4	M4	11	1.5	30	15	0.6	0.7	0.0190
Further informations Diameter: 4 mm Weight: 0.0190 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30863-0500-02	5	M4	11	1.5	35	20	0.6	0.7	0.0290
Further informations Diameter: 5 mm Weight: 0.0290 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30863-0600-02	6	M4	11	1.5	35	20	0.6	0.7	0.0290
Further informations Diameter: 6 mm Weight: 0.0290 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30863-0800-02	8	M4	11	1.5	35	20	0.6	0.7	0.0260
Further informations Diameter: 8 mm Weight: 0.0260 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
