Rope cone with internal thread, swivel swaged

제품 라인업 — Carriers · Wire rope cones

Rope cone with internal thread, swivel swaged
No. ø a b c ø d kg
30859-0300-01 3 M12 90 35 30 0.1700
30859-0400-01 4 M12 90 35 30 0.1660
30859-0500-01 5 M12 125 35 42 0.4890

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
