Cross clamp adjustable

제품 라인업 — Clamps · Cross clamps

Cross clamp adjustable

No.	ø	a	b1	b2	ø d	sw	kg
30858-0200-01	2	M12	15,5	4.5	20	6	0.0280
Further informations Diameter: 2 mm Weight: 0.0280 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0300-01	3	M12	17,5	5	20	6	0.0290
Further informations Diameter: 3 mm Weight: 0.0290 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0400-01	4	M12	19,5	5.5	20	6	0.0360
Further informations Diameter: 4 mm Weight: 0.0360 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0500-01	5	M12	21,5	6	20	6	0.0310
Further informations Diameter: 5 mm Weight: 0.0310 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0600-01	6	M12	23,5	6.5	20	6	0.0310
Further informations Diameter: 6 mm Weight: 0.0310 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
