Cross clamp adjustable two-way

제품 라인업 — Clamps · Cross clamps

Cross clamp adjustable two-way

No.	ø	b1	b3	ø d	sw	kg
30858-0800-01	8	25	12	40	10	0.1780
Further informations Diameter: 8 mm Weight: 0.1780 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-1000-01	10	25	12	40	10	0.1600
Further informations Diameter: 10 mm Weight: 0.1600 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-1200-01	12	26	12	42	10	0.1600
Further informations Diameter: 12 mm Weight: 0.1600 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
