Cross clamp adjustable with internal thread

제품 라인업 — Clamps · Cross clamps

Cross clamp adjustable with internal thread

No.	ø	a1	a2	b1	b2	c	ø d	sw	kg
30858-0200-02	2	M12	M8	27	16	10	20	6	0.0520
Further informations Diameter: 2 mm Weight: 0.0520 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0300-02	3	M12	M8	29	16.5	10	20	6	0.0530
Further informations Diameter: 3 mm Weight: 0.0530 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0400-02	4	M12	M8	31	17	10	20	6	0.0540
Further informations Diameter: 4 mm Weight: 0.0540 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0500-02	5	M12	M8	33	17.5	10	20	6	0.0550
Further informations Diameter: 5 mm Weight: 0.0550 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0600-02	6	M12	M8	35	18	10	20	6	0.0550
Further informations Diameter: 6 mm Weight: 0.0550 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
