2-part clamp ring self-assembly

제품 라인업 — Clamps · Rope clamps

2-part clamp ring self-assembly

No.	ø	a	b	ø d	sw	F_Rd kN	F_rk kN	kg
30873-0300	3	M4	27	22	3	1.21	1.5	0.0690
Further informations Diameter: 3 mm Weight: 0.0690 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30873-0400	4	M4	27	22	3	1.21	1.5	0.0690
Further informations Diameter: 4 mm Weight: 0.0690 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30873-0500	5	M6	42	28	3	1.87	2.3	0.1740
Further informations Diameter: 5 mm Weight: 0.1740 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30873-0600	6	M6	42	28	3	1.87	2.3	0.1650
Further informations Diameter: 6 mm Weight: 0.1650 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30873-0800	8	M6	42	28	3	1.87	2.3	0.1680
Further informations Diameter: 8 mm Weight: 0.1680 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
