Clip Simplex Stainless steel

제품 라인업 — Clamps · Rope clamps

Clip Simplex Stainless steel

No.	ø	a	b1	b2	k1	k2	kg
30810-0200	2	M4	15	12	12	5	0.0046
Further informations Surface: polished Diameter: 2 mm Weight: 0.0046 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30810-0300	3	M4	17	14	12	6	0.0072
Further informations Surface: polished Diameter: 3 mm Weight: 0.0072 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30810-0400	4	M5	21	17	17	8	0.0127
Further informations Surface: polished Diameter: 4 mm Weight: 0.0127 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30810-0500	5	M5	25	20	17	9	0.0146
Further informations Surface: polished Diameter: 5 mm Weight: 0.0146 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30810-0600	6	M6	30	24	23	10	0.0252
Further informations Surface: polished Diameter: 6 mm Weight: 0.0252 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30810-0800	8	M8	36.5	30	28	14	0.0542
Further informations Surface: polished Diameter: 8 mm Weight: 0.0542 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
