Wire rope clip Stainless steel

제품 라인업 — Clamps · Rope clamps

Wire rope clip Stainless steel

No.	ø	a	b1	b2	b3	b4	k	kg
30800-0200	2	M3	17	10	15	4	15	0.0100
Further informations Surface: polished Diameter: 2 mm Weight: 0.0100 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30800-0300	3	M3	21	12	16	5	15	0.0100
Further informations Surface: polished Diameter: 3 mm Weight: 0.0100 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30800-0400	4	M4	24	13	19	6	18	0.0200
Further informations Surface: polished Diameter: 4 mm Weight: 0.0200 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30800-0500	5	M5	27	16	22	7	21	0.0300
Further informations Surface: polished Diameter: 5 mm Weight: 0.0300 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30800-0600	6	M6	33	17	28	8	23	0.0400
Further informations Surface: polished Diameter: 6 mm Weight: 0.0400 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30800-0800	8	M8	41	20	35	10	28	0.0800
Further informations Surface: polished Diameter: 8 mm Weight: 0.0800 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30800-1000	10	M10	51	23	45	12	36	0.1500
Further informations Surface: polished Diameter: 10 mm Weight: 0.1500 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30800-1200	12	M12	63	28	50	14	38	0.2300
Further informations Surface: polished Diameter: 12 mm Weight: 0.2300 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30800-1600	16	M14	79	35	60	18	47	0.4100
Further informations Surface: polished Diameter: 16 mm Weight: 0.4100 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
