Suspension-rope clamp for rope Ø 6 + 8 mm

제품 라인업 — Clamps · Suspension-rope clamps

Suspension-rope clamp for rope Ø 6 + 8 mm

No.	ø	a	b1	b2	c	k	ø d1	ø d2	kg
30858-0600-10	6	M8	27	16	15	5	40	20	0.1950
Further informations Diameter: 6 mm Weight: 0.1950 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0600-25	6	M8	27	16	25	5	40	20	0.1950
Further informations Diameter: 6 mm Weight: 0.1950 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0800-10	8	M8	27	16	15	5	40	20	0.1940
Further informations Diameter: 8 mm Weight: 0.1940 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30858-0800-25	8	M8	27	16	25	5	40	20	0.1940
Further informations Diameter: 8 mm Weight: 0.1940 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
