Clevis Classic SA self-assembly

제품 라인업 — Clevises · Clevis swaged and self-assembly

Clevis Classic SA self-assembly

No.	ø	b	e	f	g	h	ø d1	ø d2	kg
30959-0200	2	40	7	10	8	13	5	5	0.0130
Further informations Diameter: 2 mm Weight: 0.0130 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30959-0300	3	52	7	10	8	13	6	6	0.0160
Further informations Diameter: 3 mm Weight: 0.0160 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30959-0400	4	63	11	15	10	18	7	7	0.0340
Further informations Diameter: 4 mm Weight: 0.0340 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30959-0500	5	75	13	16	13	22	8	8	0.0170
Further informations Diameter: 5 mm Weight: 0.0170 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30959-0600	6	95	15	20	13	25	10	10	0.1030
Further informations Diameter: 6 mm Weight: 0.1030 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30959-0800	8	128	19	24	16	32	13	12	0.1780
Further informations Diameter: 8 mm Weight: 0.1780 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
