제품 라인업 — Clevises · Clevis swaged and self-assembly
| No. | ø | b | e | f | g | h | ø d | F_Rd kN ETA | kg | |
|---|---|---|---|---|---|---|---|---|---|---|
| 30981-0400-01 | 4 | 35 | 7 | 10 | 8 | 13 | 5 | 0.0200 | ||
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30981-0500-01 | 5 | 38 | 7 | 10 | 8 | 13 | 5 | 0.0330 | ||
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30981-0600-01 | 6 | 56 | 13 | 16 | 13 | 22 | 8 | 9.5 | 0.0330 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30981-0800-01 | 8 | 68 | 15 | 20 | 13 | 25 | 10 | 20.5 | 0.0330 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
