Clevis Monofork swaged

제품 라인업 — Clevises · Clevis swaged and self-assembly

Clevis Monofork swaged

No.	ø	b	e	f	g	h	ø d1	ø d2	kg
30847-0300	3	70	7	14	8	16	6	6.3	0.0330
Further informations Diameter: 3 mm Weight: 0.0330 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30847-0400	4	80	7	14	8	16	6	7.5	0.0380
Further informations Diameter: 4 mm Weight: 0.0380 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30847-0500	5	92	8.5	15.5	10	18	8	9	0.0600
Further informations Diameter: 5 mm Weight: 0.0600 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30847-0600	6	112	10.5	19.5	12	21.5	9	12.7	0.1220
Further informations Diameter: 6 mm Weight: 0.1220 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30847-0800	8	150	18	24	16	30	12	16	0.3000
Further informations Diameter: 8 mm Weight: 0.3000 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
