Clevis swaged PHASED-OUT ITEM

제품 라인업 — Clevises · Clevis swaged and self-assembly

Clevis swaged PHASED-OUT ITEM

No.	ø	b	e	f	g	h	ø d1	ø d2	kg
30881-0200	2	65	6	12	7.5	12.5	5	5.5	0.0200
Further informations Diameter: 2 mm Weight: 0.0200 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30881-0300	3	70	6	12	7.5	12.5	5	6.3	0.0230
Further informations Diameter: 3 mm Weight: 0.0230 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30881-0600	6	112	11	19	12	20.5	9.5	12.5	0.1080
Further informations Diameter: 6 mm Weight: 0.1080 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30881-0800	8	143	14	25	14	26	12	16	0.2210
Further informations Diameter: 8 mm Weight: 0.2210 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30881-1000	10	166	18	32	22	34	14	18	0.3600
Further informations Diameter: 10 mm Weight: 0.3600 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30881-1200	12	205	18	32	22	34	16	20	0.4890
Further informations Diameter: 12 mm Weight: 0.4890 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
