Clevis and internal thread-end left-hand swaged for rope Ø 10 - 16 mm. PHASED-OUT ITEM

제품 라인업 — Clevises · Clevis with internal thread swaged

Clevis and internal thread-end left-hand swaged for rope Ø 10 - 16 mm. PHASED-OUT ITEM
No. ø a b e f g h ø d1 ø d2 - + kg
30811-1000-01 10 M 12 289 14 25 14 26 12 20 40 19 0.5100
30811-1200-01 12 M 16 341 18 32 22 34 14 24 42 21 0.7750
30811-1600-01 16 M 20 422 23 43 24 43 19 30 65 25 1.7890

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
