Clevis and internal thread end right-hand swaged for rope Ø 3 - 8 mm. PHASED-OUT ITEM

제품 라인업 — Clevises · Clevis with internal thread swaged

Clevis and internal thread end right-hand swaged for rope Ø 3 - 8 mm. PHASED-OUT ITEM
No. ø a b e f g h ø d1 ø d2 - + kg
30812-0300-01 3 M 5 94 6 12 7.5 12.5 5 7 8 5 0.0320
30812-0300-02 3 M 5 110 6 12 7.5 12.5 5 7 15 13 0.0400
30812-0400-01 4 M 6 95 6 12 7.5 12.5 5 8 8 3 0.0370
30812-0400-02 4 M 6 120 6 12 7.5 12.5 5 8 15 11 0.0450
30812-0500-01 5 M 6 105 6 12 7.5 12.5 5 8 8 3 0.0350
30812-0500-02 5 M 6 128 6 12 7.5 12.5 5 8 15 11 0.0440
30812-0600-01 6 M 8 125 7 13 10 14.5 6 10 10 3 0.0670
30812-0600-02 6 M 8 162 7 13 10 14.5 6 10 25 13 0.0840
30812-0800-01 8 M 10 204 9 15 11 18 8 13 30 10 0.1860

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
