제품 라인업 — Clevises · Clevis with internal thread swaged
| No. | ø | a | b | e | f | g | h | ø d1 | ø d2 | - | + | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 30932-1000-01 | 10 | M12 | 271 | 19 | 24 | 16 | 32 | 12 | 18 | 35 | 17 | 0.4450 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
| 30932-1200-01 | 12 | M16 | 341 | 23 | 32 | 22 | 38 | 14 | 24 | 42 | 21 | 0.8410 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
| 30932-1600-01 | 16 | M20 | 417 | 30 | 38 | 22 | 50 | 20 | 30 | 49 | 25 | 1.7600 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
