제품 라인업 — Clevises · Clevis with thread
| No. | a | b | c | e | f | g | h | ø d | kg | |
|---|---|---|---|---|---|---|---|---|---|---|
| 30961-0500 | M5 | 35 | 7.5 | 7 | 10 | 8 | 13 | 5 | 0.0162 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30961-0600 | M6 | 38 | 9 | 7 | 10 | 8 | 13 | 5 | 0.0174 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30961-0800 | M8 | 56 | 12 | 13 | 16 | 13 | 22 | 8 | 0.0556 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30961-1000 | M10 | 68 | 15 | 15 | 20 | 13 | 25 | 10 | 0.0978 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
