제품 라인업 — Clevises · Clevis with thread
| No. | a | b | c | e | f | g | h | ø d | F_Rd kN ETA | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 30971-0500-01 | M5 | 54 | 30 | 7 | 10 | 8 | 13 | 5 | 6.1 | 0.0190 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30971-0600-01 | M6 | 55 | 30 | 7 | 10 | 8 | 13 | 5 | 8.7 | 0.0210 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30971-0800-01 | M8 | 74 | 35 | 13 | 16 | 13 | 22 | 5 | 15.8 | 0.0640 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
