제품 라인업 — Clevises · Clevis with thread
| No. | a | b | c | e | f | g | h | ø d | kg | |
|---|---|---|---|---|---|---|---|---|---|---|
| 30817-0500-01 | M5 | 36 | 7.5 | 6 | 12 | 7.5 | 12.5 | 5 | 0.0170 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30817-0600-01 | M6 | 39 | 9 | 6 | 12 | 7.5 | 12.5 | 5 | 0.0170 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30817-0800-01 | M8 | 46 | 12 | 7 | 13 | 10 | 14.5 | 6 | 0.0250 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30817-1000-01 | M10 | 56 | 15 | 9 | 15 | 11 | 18 | 8 | 0.0540 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
