Clevis Monofork with external thread right-hand

제품 라인업 — Clevises · Clevis with thread

Clevis Monofork with external thread right-hand

No.	a	b	c	e	f	g	h	ø d	kg
30845-0600	M6	80	45	7,0	14	8,0	16,0	6	0.0350
Further informations Weight: 0.0350 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30845-0600-01	M6	65	30	7,0	14	8	16,0	6	0.0320
Further informations Weight: 0.0320 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30845-0800	M8	100	60	8,5	15,5	10,0	18,0	8	0.0630
Further informations Weight: 0.0630 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30845-0800-01	M8	75	35	8,5	15,5	10,0	18,0	8	0.0560
Further informations Weight: 0.0560 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30845-1000	M10	118	63	10,5	19,5	12,0	21,5	9	0.1090
Further informations Weight: 0.1090 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30845-1200	M12	150	80	18,0	24	16	30,0	12	0.2600
Further informations Weight: 0.2600 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
