Clevis with external thread left-hand PHASED-OUT ITEM

제품 라인업 — Clevises · Clevis with thread

Clevis with external thread left-hand PHASED-OUT ITEM

No.	a	b	c	e	f	g	h	ø d	kg
30872-0500	M 5	66	41	6	12	7.5	12.5	5	0.0190
Further informations Weight: 0.0190 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30872-0500-01	M 5	55	30	6	12	7.5	12.5	5	0.0180
Further informations Weight: 0.0180 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30872-0600	M 6	73	47	6	12	7.5	12.5	6	0.0220
Further informations Weight: 0.0220 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30872-0600-01	M 6	56	30	6	12	7.5	12.5	5	0.0190
Further informations Weight: 0.0190 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30872-0800	M 8	86	57	7	13	10	14.5	6	0.0390
Further informations Weight: 0.0390 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30872-0800-01	M 8	64	35	7	13	10	14.5	6	0.0320
Further informations Weight: 0.0320 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30872-1200	M 12	132	80	14	25	14	26	12	0.1680
Further informations Weight: 0.1680 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30872-1600	M 16	166	100	18	32	22	34	14	0.3970
Further informations Weight: 0.3970 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
