Clevis with external thread right-hand PHASED-OUT ITEM

제품 라인업 — Clevises · Clevis with thread

Clevis with external thread right-hand PHASED-OUT ITEM
No. a b c e f g h ø d kg
30871-0500 M 5 66 41 6 12 7.5 12.5 5 0.0190
30871-0500-01 M 5 55 30 6 12 7.5 12.5 5 0.0180
30871-0600 M 6 73 47 6 12 7.5 12.5 5 0.0220
30871-0600-01 M 6 56 30 6 12 7.5 12.5 5 0.0190
30871-0800 M 8 86 57 7 13 10 14.5 6 0.0390
30871-0800-01 M 8 64 35 7 13 10 14.5 6 0.0320
30871-1200 M 12 132 80 14 25 14 26 12 0.1680
30871-1600 M 16 166 100 18 32 22 34 14 0.3970
30871-2000 M 20 212 120 23 43 24 43 19 0.7260

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
