Clevis with internal thread left-hand

제품 라인업 — Clevises · Clevis with thread

Clevis with internal thread left-hand

No.	a	b	c	e	f	g	ø d1	ø d2	kg
30818-0400	M4	29	12	7	7	3.5	4	10	0.0130
Further informations Weight: 0.0130 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30818-0500	M5	36	15	8	9	5	5	12	0.0220
Further informations Weight: 0.0220 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30818-0600	M6	43	18	9	10	6	6	14	0.0360
Further informations Weight: 0.0360 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30818-0800	M8	54	27	12	12.5	7	8	18	0.0670
Further informations Weight: 0.0670 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30818-1000	M10	66	32	15	15	8	10	22	0.1340
Further informations Weight: 0.1340 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30818-1200	M12	78	38	17	18	10	12	26	0.2000
Further informations Weight: 0.2000 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
