Turnbuckle with clevis Classic SA Self-Assembly

제품 라인업 — Clevises · Clevis with turnbuckle swaged and self-assembly

Turnbuckle with clevis Classic SA Self-Assembly
No. ø a b1 b2 e f g h ø d1 ø d2 - + kg
30980-0300 3 M6 205 92 7 10 8 13 5 10 44 22 0.0750
30980-0400 4 M6 215 92 11 15 10 18 7 10 44 22 0.0990
30980-0500 5 M8 243 112 13 16 13 22 8 13.5 51 26 0.1830
30980-0600 6 M10 275 120 15 20 13 25 10 17.2 54 20 0.2900
30980-0600-1 6 M8 255 112 13 16 13 22 8 13.5 51 26 0.1830
30980-0800 8 M12 353 150 19 24 16 32 12 21.5 70 34 0.5390
30980-0800-1 8 M10 302 120 15 20 13 25 10 17.2 54 20 0.2900
