제품 라인업 — Clevises · Clevis with turnbuckle swaged and self-assembly
| No. | ø | a | b1 | b2 | e | f | g | h | ø d | - | + | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 30970-1600 | 16 | M24 | 570 | 212 | 38 | 45 | 28 | 65 | 25 | 94 | 46 | 3.5080 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
| 30970-2000 | 20 | M30 | 707 | 268 | 45 | 68 | 32 | 74 | 30 | 118 | 60 | 7.0260 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
