제품 라인업 — Clevises · Clevis with turnbuckle swaged and self-assembly
| No. | ø | a | b1 | b2 | e | f | g | h | ø d | - | + | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 30970-0500-10 | 5 | M5 | 149 | 80 | 7 | 10 | 8 | 13 | 5 | 22 | 16 | 0.0450 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
| 30970-0500-11 | 5 | M5 | 180 | 80 | 7 | 10 | 8 | 13 | 5 | 34 | 26 | 0.0500 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
| 30970-0600-10 | 6 | M6 | 168 | 92 | 7 | 10 | 8 | 13 | 5 | 20 | 12 | 0.0670 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
| 30970-0600-11 | 6 | M6 | 205 | 92 | 7 | 10 | 8 | 13 | 5 | 44 | 22 | 0.0780 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
| 30970-0800-10 | 8 | M8 | 211 | 112 | 13 | 16 | 13 | 22 | 8 | 17 | 6 | 0.1400 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
| 30970-0800-11 | 8 | M8 | 243 | 112 | 13 | 16 | 13 | 22 | 8 | 51 | 26 | 0.1610 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
