Toggle Forte
No. b1 b2 e f g h k ø d kg
32817-1200-05 90 60 15 24 14 31 12 12 0.3180
32817-1600-05 117 77 20 30 18 40 16 16 0.6920
32817-2000-05 142 94 24 38 22 48 20 20 1.2420
32817-2400-05 175 117 29 48 26 58 24 25 2.1850
32817-3000-05 223 147 38 60 32 75 30 32 4.6530
32817-3600-05 260 170 45 48 38 90 36 36 7.8070

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
