Variball MK 1 rigth-hand

제품 라인업 — End stops · End fittings Variball

Variball MK 1 rigth-hand

No.	a	c	ø d	kg
30898-0300-01	M3	7	12	0.0060
Further informations Weight: 0.0060 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30898-0400-01	M4	9	16	0.0150
Further informations Weight: 0.0150 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30898-0500-01	M5	9	16	0.0150
Further informations Weight: 0.0150 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30898-0600-01	M6	11	20	0.0280
Further informations Weight: 0.0280 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30898-0800-01	M8	12	24	0.0490
Further informations Weight: 0.0490 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30898-1000-01	M10	12	24	0.0450
Further informations Weight: 0.0450 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
