End-stop with countersunk head 90° swaged

제품 라인업 — End stops · End stops assembled

End-stop with countersunk head 90° swaged
No. ø b1 b2 ø d1 ø d2 kg
30866-0200 2 18 15 5 8.3 0.0020
30866-0300 3 30 26 6 10.4 0.0080
30866-0400 4 32 28 7 10.4 0.0100
30866-0500 5 41 37 8 12.4 0.0130
30866-0600 6 50 47 10 12.4 0.0240
30866-0800 8 79 72 13 20.5 0.0470

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
