End-stop with countersunk head 90° Univiss round swaged

제품 라인업 — End stops · End stops assembled

End-stop with countersunk head 90° Univiss round swaged

No.	ø	b1	b2	ø d1	ø d2	kg
30866-0300-11	3	8	6	4	6.3	0.0030
Further informations Diameter: 3 mm Weight: 0.0030 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30866-0400-11	4	11	8	5	8.3	0.0040
Further informations Diameter: 4 mm Weight: 0.0040 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30866-0500-11	5	13	10	6	8.3	0.0060
Further informations Diameter: 5 mm Weight: 0.0060 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30866-0600-11	6	15	11	8	10.4	0.0130
Further informations Diameter: 6 mm Weight: 0.0130 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30866-0800-11	8	20	17	10	12.4	0.0320
Further informations Diameter: 8 mm Weight: 0.0320 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
