End-stop with radius head swaged

제품 라인업 — End stops · End stops assembled

End-stop with radius head swaged

No.	ø	b1	b2	ø d1	ø d2	kg
30869-0200	2	18	15	5	8	0.0060
Further informations Diameter: 2 mm Weight: 0.0060 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0300	3	30	26	6	10	0.0080
Further informations Diameter: 3 mm Weight: 0.0080 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0400	4	32	28	7	12	0.0100
Further informations Diameter: 4 mm Weight: 0.0100 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0500	5	42	37	8	14	0.0150
Further informations Diameter: 5 mm Weight: 0.0150 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0600	6	53	47	10	16	0.0270
Further informations Diameter: 6 mm Weight: 0.0270 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0800	8	80	72	13	22	0.0500
Further informations Diameter: 8 mm Weight: 0.0500 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
