End-stop with radius head Univiss round swaged

제품 라인업 — End stops · End stops assembled

End-stop with radius head Univiss round swaged

No.	ø	b1	b2	ø d1	ø d2	kg
30869-0300-11	3	9	6.5	4	6	0.0030
Further informations Diameter: 3 mm Weight: 0.0030 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0400-11	4	11	7.6	5	8	0.0040
Further informations Diameter: 4 mm Weight: 0.0040 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0500-11	5	13	9.5	6	10	0.0070
Further informations Diameter: 5 mm Weight: 0.0070 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0600-11	6	15	11	8	12	0.0140
Further informations Diameter: 6 mm Weight: 0.0140 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0800-11	8	20	14	10	16	0.0360
Further informations Diameter: 8 mm Weight: 0.0360 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
