Countersunk head 90° Unistopp with internal thread

제품 라인업 — End stops · End stops with internal thread

Countersunk head 90° Unistopp with internal thread
No. a b1 b2 c ø d1 ø d2 kg
30866-0300-10 M3 8 6 4.5 4 6.3 0.0010
30866-0400-10 M4 11 8 6 5 8.3 0.0010
30866-0500-10 M5 13 10 7.5 6 8.3 0.0010
30866-0600-10 M6 15 11 9 8 10.4 0.0030
30866-0800-10 M8 20 17 12 10 12.4 0.0080

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
