제품 라인업 — End stops · End stops with internal thread
| No. | a | b1 | b2 | c | ø d1 | ø d2 | sw | kg | |
|---|---|---|---|---|---|---|---|---|---|
| 30869-0400-02 | M4 | 29 | 25 | 15 | 6 | 10 | 3 | 0.0080 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30869-0500-02 | M5 | 34 | 30 | 20 | 7 | 12 | 3 | 0.0100 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30869-0600-02 | M6 | 35 | 30 | 20 | 8 | 14 | 4 | 0.0111 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30869-0800-02 | M8 | 40 | 34 | 25 | 10 | 16 | 5 | 0.0170 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
