Radius head Unistopp with internal thread

제품 라인업 — End stops · End stops with internal thread

Radius head Unistopp with internal thread

No.	a	b1	b2	c	ø d1	ø d2	kg
30869-0300-10	M3	9	6.5	4.5	4	6	0.0010
Further informations Weight: 0.0010 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0400-10	M4	11	7.6	6	5	8	0.0010
Further informations Weight: 0.0010 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0500-10	M5	13	9.5	7.5	6	10	0.0020
Further informations Weight: 0.0020 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0600-10	M6	15	11	9	8	12	0.0040
Further informations Weight: 0.0040 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30869-0800-10	M8	20	14	12	10	16	0.0110
Further informations Weight: 0.0110 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
