Radius head rope self-assembly Set

제품 라인업 — End stops · Radius head rope

Radius head rope self-assembly Set

No.	ø	a	b1	b2	b3	L	ø d1	ø d2	ø d3	sw	WLL kN	kg
30780-0400-020	4	M6	76	41	29	2000	9.5	16	7	4	2.3	0.2140
Further informations Diameter: 4 mm Weight: 0.2140 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30780-0400-030	4	M6	76	41	29	3000	9.5	16	7	4	2.3	0.2880
Further informations Diameter: 4 mm Weight: 0.2880 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30780-0400-040	4	M6	76	41	29	4000	9.5	16	7	4	2.3	0.3620
Further informations Diameter: 4 mm Weight: 0.3620 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30780-0400-060	4	M6	76	41	29	6000	9.5	16	7	4	2.3	0.5100
Further informations Diameter: 4 mm Weight: 0.5100 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
