제품 라인업 — Eye-ends · Eye-end swaged and self-assembly
| No. | ø | b1 | b2 | e | h | k | ø d1 | ø d2 | F_Rd kN | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 30941-0200 | 2 | 35 | 14 | 7 | 12.5 | 3 | 5.5 | 5 | 1.1 | 0.0050 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30941-0300 | 3 | 48 | 17 | 8 | 13.5 | 4 | 6.5 | 6 | 2.5 | 0.0100 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30941-0400 | 4 | 55 | 21 | 9 | 17 | 5 | 8.5 | 7 | 4.4 | 0.0150 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30941-0500 | 5 | 68 | 27 | 11 | 21 | 6 | 10.5 | 8 | 6.1 | 0.0240 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30941-0600 | 6 | 82 | 29 | 13.5 | 25 | 8 | 13 | 10 | 8.7 | 0.0450 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30941-0800 | 8 | 116 | 37 | 15 | 30 | 10 | 15 | 13 | 17.8 | 0.0970 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
