제품 라인업 — Eye-ends · Eye-end swaged and self-assembly
| No. | ø | b | e | f | k | ø d1 | ø d2 | sw | F_Rd kN | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 30853-0200-01 | 2 | 62 | 8 | 10.5 | 6 | 6 | 14 | 13 | 1.8 | 0.0500 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30853-0300-01 | 3 | 62 | 8 | 10.5 | 6 | 6 | 14 | 13 | 3.4 | 0.0500 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30853-0400-01 | 4 | 62 | 8 | 10.5 | 6 | 6 | 14 | 13 | 6.1 | 0.0500 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30853-0500-01 | 5 | 80 | 10.5 | 14 | 7 | 8 | 18 | 15 | 9.2 | 0.0990 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30853-0600-01 | 6 | 80 | 10.5 | 14 | 7 | 8 | 18 | 15 | 11.4 | 0.0970 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30853-0800-01 | 8 | 116 | 15 | 20 | 10 | 12 | 26 | 22 | 22.8 | 0.2950 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
| 30853-1000-01 | 10 | 149 | 19 | 25 | 12 | 16 | 34 | 30 | 31.3 | 0.6400 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
