Eye-end and internal thread-end left-hand swaged for rope Ø 10 - 16 mm

제품 라인업 — Eye-ends · Eye-end with internal thread swaged

Eye-end and internal thread-end left-hand swaged for rope Ø 10 - 16 mm
No. ø a b1 b2 e h k ø d1 ø d2 - + kg
30813-1000-01 10 M12 258 31 14 25 8 13 18 30 15 0.3790
30813-1200-01 12 M16 322 37 15 31 10 14.5 24 39 26 0.7940
30813-1600-01 16 M20 392 49 21 40 15 19.5 30 44 30 1.4830

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
