제품 라인업 — Eye-ends · Eye-end with internal thread swaged
| No. | ø | a | b1 | b2 | e | h | k | ø d1 | ø d2 | - | + | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 30814-1000-01 | 10 | M12 | 258 | 31 | 14 | 25 | 8 | 13 | 18 | 30 | 15 | 0.3790 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
| 30814-1200-01 | 12 | M16 | 322 | 37 | 15 | 31 | 10 | 14.5 | 24 | 39 | 26 | 0.7940 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
| 30814-1600-01 | 16 | M20 | 392 | 49 | 21 | 40 | 15 | 19.5 | 30 | 44 | 30 | 1.4830 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
