Eye-end with internal thread right-hand

제품 라인업 — Eye-ends · Eye-end with thread

Eye-end with internal thread right-hand

No.	a	b	c	e	f	k	ø d1	ø d2	kg
30806-0400	M4	32	12	6	7.5	3.4	4	10	0.0120
Further informations Weight: 0.0120 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30806-0500	M5	39	15	7	9	4.9	5	12	0.0300
Further informations Weight: 0.0300 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30806-0600	M6	46	18	8	10.5	5.9	6	14	0.0400
Further informations Weight: 0.0400 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30806-0800	M8	62	27	10.5	14	6.9	8	18	0.0700
Further informations Weight: 0.0700 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30806-1000	M10	74	32	13	17	7.9	10	22	0.1310
Further informations Weight: 0.1310 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30806-1200	M12	88	38	15	20	9.9	12	26	0.2230
Further informations Weight: 0.2230 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30806-1600	M16	112	50	19	25	11.9	16	34	0.4000
Further informations Weight: 0.4000 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30806-2000	M20	140	62	24	31	14.9	20	42	1.0500
Further informations Weight: 1.0500 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
