제품 라인업 — Eye-ends · Eye-end with turnbuckle swaged and self-assembly
| No. | ø | a | b1 | b2 | b3 | e | h | k | ø d | WLL kN | - | + | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 30889-0500-11 | 5 | M5 | 178 | 80 | 15 | 6 | 12 | 3 | 5.5 | 3.8 | 34 | 26 | 0.0410 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||||||
| 30889-0600-11 | 6 | M6 | 201 | 92 | 16 | 7 | 14 | 4 | 6.5 | 44 | 22 | 0.0670 | ||
Further informations
Price basis / tiered pricesPrice on request |
||||||||||||||
| 30889-0800-11 | 8 | M8 | 238 | 112 | 21 | 8.5 | 17 | 5 | 8.5 | 51 | 26 | 0.1510 | ||
Further informations
Price basis / tiered pricesPrice on request |
||||||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
