Wall anchor with internal thread Stainless steel type m2r-I

제품 라인업 — Fasteners · Fixing and assembly technology

Wall anchor with internal thread Stainless steel type m2r-I
No. a b2 c2 kg
30803-0600-22 M6 45 15 0.0130
30803-0800-22 M8 51 17 0.0220
30803-1000-22 M10 55 17 0.0360
30803-1200-22 M12 69 18 0.0830

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
