Cylinder screw hexagon socket
No. a c2 k2 ø d1 sw kg
30844-0400 M4 25 4 7 3 0.0030
30844-0500 M5 25 5 8.5 4 0.0050
30844-0600 M6 30 6 10 5 0.0080
30844-0800 M8 35 8 13 6 0.0175
30844-0800-020 M8 20 8 13 6 0.0134
30844-0800-025 M8 25 8 13 6 0.0145
30844-0800-045 M8 45 8 13 6 0.0250
30844-1000 M10 40 10 16 8 0.0320
30844-1200 M12 50 12 18 10 0.0530
30844-1600 M16 60 16 24 14 0.1160

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
