Eye bolt

제품 라인업 — Fasteners · Screws and standard parts

Eye bolt

No.	a	b	c1	ø d1	ø d2	ø d3	ø d4	kg
30837-0600	M6	27	11	27	15	15	6	0.0190
Further informations Weight: 0.0190 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30837-0800	M8	36	13	36	20	20	8	0.0450
Further informations Weight: 0.0450 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30837-1000	M10	45	17	45	25	25	10	0.0910
Further informations Weight: 0.0910 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30837-1200	M12	53	20	54	30	30	12	0.1520
Further informations Weight: 0.1520 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30837-1600	M16	62	27	63	35	35	14	0.2590
Further informations Weight: 0.2590 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30837-2000	M20	71	30	72	40	40	16	0.3870
Further informations Weight: 0.3870 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30837-2400	M24	90	36	90	50	50	20	0.7610
Further informations Weight: 0.7610 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
